Balance shaft oil seal
AZ9114520223 oil-seal 160×185×10.5mm
| Product name | Product Model | Product number (specification) |
Applicable models |
Installation location |
Product Benefits | Product Advantages | |
| Balance shaft oil seal | AZ9114520223 | 160*185*10.5 | Sinotruk Steyr Universal for many models such as Howo |
Balance shaft | Robust sealing performance, excellent wear resistance, excellent heat resistance, strong corrosion resistance, good oil resistance properties, excellent pressure-bearing qualities | The skeleton-type oil seal utilizes cutting-edge vacuum vulcanization techniques to ensure a robust fusion between the rubber and the metal frame, resulting in a stable seal structure with an extended operational lifespan. It incorporates premium-quality springs to enhance lubrication and sealing performance around rotating shafts, effectively partitioning the oil chamber from the external environment. Internally, it safeguards against the leakage of oils or water-based chemical fluids within machinery, while externally it shields mechanical parts from damage caused by the ingress of dust and particulates. | |
Above the tyres of the car. Balancer shafts can be divided into two types: single balancer shafts and double balancer shafts. A single balance shaft, as its name implies, uses a single balance shaft and operates by means of gearing, whereby the crankshaft rotates to drive the solidly attached balance shaft drive gear, the balance shaft driven gear and the balance shaft. Single balance shaft can balance the proportion of the whole vibration is quite large first-order vibration, so that the engine vibration has been significantly improved. Determine the installation direction of the oil seal lip according to different usage requirements: single lip oil seal is used to prevent oil leakage, then the lip should be installed to the bearing side. The main lip of the double-lip oil seal should be inward, and the secondary lip should be outward. The assembly surface of the oil seal is flush with the reference surface of the shell to ensure the installation perpendicularity with the shaft centre after mounting the shaft, so that the lip of the oil seal becomes a line contact zone on the shaft surface to achieve good sealing effect.
